$13.50
Final Screw - Multiunit (RP) with 0.048/1.20 Hex - 19.055
- Multiunit, Compatible
- SKU:
- 19.055
- Platform Size:
- 4.8
- Platform Name:
- Multiunit RP
YOU MIGHT ALSO NEED
The final screw requires the use of a 0.048/1.20 Hex screwdriver and is for use with the following DESS multiunit parts - 15.007, 15.007/8, 24.007, 28.007, 11.007-P10.
Torque is 15Ncm.
All of our screws are stress tested to 150% of the nominal torque value and can also be used as lab screws.
REF | DESCRIPTION | HEAD DIAMETER | HEAD BASE ANGLE | OVERALL LENGTH | HEAD LENGTH | DISTANCE FROM HEAD TO THREAD | THERAD LENGTH | THREAD TYPE | RECOMMENDED TORQUE VALUE | SOCKET |
19.055 | Screw HEX 0.048"/1.20 mm on Multi-Unit® RP |
2 | 0° | 3.45 | 1.35 | 0 | 2.1 | M1.4 | 15 Ncm | HEX 0.048" / 1.20 mm |
19.006 | Screw UG on Multi-Unit® RP | 2 | 0° | 3.45 | 1.35 | 0 | 2.1 | M1.4 | 15 Ncm | Unigrip® |
